LCDD

Technical parameters:

·        Model: LSDD-16, LSDD-18, LSDD-21

·        Power supply: AC 230V 50Hz (AC 120V 60Hz) AC 230V 50Hz (AC 120V 60Hz) AC 230V 50Hz (AC 120V 60Hz)

·        Torque: 12N.m 22N.m 27N.m

·        The maximum weight of the door: 500 KG, 800 KG, 1000 KG

·        Motor speed: 1400r/min, 1400r/min, 1400r/min

·        Door speed: 12 m/min, 12 m/min, 12 m/min

·        Limit switch: Spring/Magnetic (NC/NO), Spring/Magnetic (N.O./N.C.), Spring/Magnetic (NC/NO)

·        Noise: ≤ 56 dB

·        Working temperature: -40℃- +65℃

·        Degree of protection: IP44

·        Authentication: CCC，CE
